Jetcord XT/C




Hoses according to API 1529 : 1998 type C - Grade 2

Description


Tube:
Black, smooth NBR rubber, resistant to aviation gasolines and jet fuels having an aromatic content up to 40%.
Reinforcement:
Synthetic textile fabrics.
Cover:
Smooth, black colour, antistatic (R between 1000 Q/m and 1 MQ/m) CR rubber, resistant to abrasion, oil, fuel, ozone and weather.






Applications

Designed for use in all operations associated with the ground refueling of aircraft.
Hoses according to API 1529 : 1998 type C - Grade 2.


Standard Lengths:

Maximum: 40m

Packing

All hose coils are wrapped in polythene film.


Tolerances

API 1529 tolerances.
On inside diameter:
Up to and including inside diameter 38mm ±
0.80mm.
From I.D. 50mm to I.D. 76mm ± 1.20mm.
For bigger I.D. ± 1.60mm
Length tolerance: ± 1%


Temperature Range

Working temperature: -40°C (-40°F) to +70°C (+158°F)
